MSCP-03 03 Series Modular Throttle And Check Valve Hydraulic

Name: MSCP-03 03 Series Modular Throttle And Check Valve Hydraulic
Brand: Guangzhou Seric Hydraulic Co., Ltd.
SKU: 03 Series
Availability: InStock

Product Details:

Place of Origin:	Guangzhou, China
Brand Name:	Seric
Certification:	CE, ISO
Model Number:	03 Series

Detail Information

Place of Origin:

Guangzhou, China

Brand Name:

Seric

Certification:

CE, ISO

Model Number:

03 Series

After Warranty Service:

Online Support

OEM:

Condition:

100% Brand-new

Quality:

High-Quality

Application:

Industrial Machinery

Selling Units:

Single Item

Highlight:

High Light

Highlight:

MSCP-03 Throttle And Check Valve

Throttle And Check Valve Hydraulic

Trading Information

Minimum Order Quantity:

1 Piece

Price:

Negotiable

Packaging Details:

Carton Box/Wooden Case

Delivery Time:

1-15 days

Payment Terms:

T/T,L/C,Western Union

Supply Ability:

5000

Product Description

Hydraulic MSCP-03 03 Series Check and Throttle Valves

Features

The modular valves are functional elements with which a hydraulic system can be composed and built easily by stacking them with the mounting bolts. Therefore, no piping is required for the manufacture of the hydraulic systems. Seric's 03 Series Modular Valves are widely used to compose the hydraulic systems for the various industrial equipment including machine tools, special purpose machines and injection moulding machines. The valves have standardized mounting surface conforming to ISO 4401-AC-05-4-A and optimum thickness for the stacking.

MSCP-03 03 Series Modular Throttle And Check Valve Hydraulic 0

Specifications

Model Numbers	Max. Operating Pressure MPa (PSI)	Max. Flow L /min (U.S.GPM)
MSCP-03-20	25 (3630)	70 (18.5)^★

Maximum flow decreases when the differential pressure is less than 0.8 MPa (115 PSI). See "Pressure Drop at Throttle Fully Open"

Model Number Designation

F-	MSCP	-3	-20
Special Seals	Series Number	Valve Size	Design Number
F: Special Seals for Phosphate Ester Type Fluids (Omit if not required)	MSCP: Check and Throttle Valve for P-Line	3	20

Typical Performance Characteristics

Hydraulic Fluid: Viscosity 35 mm²/ s (164 SSU), Specific Gravity 0.850

MSCP-03 03 Series Modular Throttle And Check Valve Hydraulic 1

MSCP-03 03 Series Modular Throttle And Check Valve Hydraulic 2

Instructions

●To make flow rate adjustment, loosen locking screw for the dial and turn the flow adjustment dial clockwise or anti-clockwise. For a decrease of flow, turn the dial clockwise. Be sure to re-tighten the locking screw firmly after the adjustment of the flow rate.

MSCP-03 03 Series Modular Throttle And Check Valve Hydraulic 3
